SINGLE ZONE

CHF High Wall Indoor Unit
CZP Condensing Outdoor Unit

PLATINUM Applications

  • Sun Room
  • Garage
  • Pool House
  • Home Gym
  • Small Office Space
  • Home Theater Room
  • Any Room Where Central Duct Work Is Not Available

CHF Series FEATURES

Previous
Next

Platinum Expanded Features:

  • LOW AMBIENT: Capable of producing comfortable. Heating and cooling to outdoor ambient temperatures as low as -13°F.
  • MANUAL POWER SWITCH: Power unit ON/OFF using button located at the evaporator.
  • INTERACTIVE DISPLAY SHOWS:
    • Error codes based on system failure.
    • Service codes if your filter needs cleaning.
    • Error code if refrigerant leak is detected.
    • When unit goes into auto defrost.
  • SELF-DIAGNOSIS: Unit will shut down and go into protection mode if it detects abnormalities. The display will show an error code depending on the type of protection the unit is in.
  • BYPASS MODE: Unit will continue to operate if a non-critical component fails, such as a sensor.
  • 2-WAY DRAINING OPTION: Ability to place drain hose on either left or right hand side of evaporator allows for flexible installation design.
  • 3 DIRECTIONAL AIRFLOW: Air flow is directed so that it reaches more surface area including the corners of the room being conditioned.
  • MUTE OPERATION: Silence from the Remote Control.
  • FOLLOW ME FUNCTION: Remote Control has a sensor built in. In this mode, the unit will sense the temperature at the Remote Control instead of at the indoor unit for the set temperature.
  • CONTROLS: Wired Controls (optional).
  • WiFi Control: Cool Link installed in unit (optional).
